Lilly

The decorative park luminaire LILLY by Vizulo combines a modernised historical design with current LED technology and has been developed specifically for urban outdoor areas such as parks, squares and pedestrian zones. Thanks to a wide choice of optics, light colours (incl. 1800–2200 K for nature-friendly, warm lighting) and control options, LILLY can be precisely adapted to different lighting tasks and municipal requirements. The robust, corrosion-protected housing in die-cast aluminium and the high efficiency of up to 8'000 lumens at up to 160 lm/W make LILLY an economical solution for municipal and commercial projects.

Key facts:

• Modernised historical design language for stylish park and city lighting
• Wide choice of optics for paths, squares and area lighting
• Flexible light colours incl. particularly warm, nature-friendly variants (e.g. 1800–2200 K)
• Intelligent control: stand-alone, group control or central CMS possible
• Compatible with NEMA and Zhaga top interfaces for smart-city applications
• Multi-level dimming options (DALI, 1–10 V, midnight and step dimming, mains dimming)
• Robust die-cast aluminium housing with powder coating and primer against corrosion
• Optional surge protection up to 10 kV for increased operational reliability outdoors

Note: We are happy to advise you on the exact specification; standard variants available from stock.

ELECTRONICS

• Primary voltage range: 198–264 V
• Frequency (Hz): 50–60
• Control gear: driver options Standard, Eco, High Density
• Power range (W): up to 55
• Interfaces (socket): NEMA Top, Zhaga Top
• Surge protection: 4 kV, 6 kV, 10 kV

LIGHTING TECHNOLOGY

• Light colour (K): 1800, 2200, 3500, 5000, 5700, 6500
• Special light colours: PC Amber, Red
• Colour rendering (CRI): 70, 80, 90
• Maximum colour deviation: MacAdam 5
• Luminous flux (lm): up to 8'000
• Luminaire efficacy (lm/W): up to 160
• Light distribution: wide choice of optics
• Lifetime: up to 100'000 h (L90B10 / L98B10)
• Dimmability: DALI, 1–10 V, midnight dimming, step dimming, mains dimming

DIMENSIONS & MATERIAL

• Weight (g): up to 10'100
• Wind load area: 0.10 m²
• Pole brackets (spigot): 60–75 mm, 76–80 mm
• Housing colours: standard colours according to manufacturer
• Luminaire body: die-cast aluminium, powder-coated with primer

FURTHER DATA

• Mounting: pole mounting, compatible with NEMA/Zhaga

The technical data is not exhaustive; if you have any questions, please feel free to contact us at any time.
